What Is Structured Text in PLC Programming?

The main programming language used for PLCs (Programmable Logic Controllers) operates as Structured Text. Structured Text in PLC programming serves as a different programming language from ladder logic since its code resembles standard computer programming syntax. Text commands allow you to handle complicated data processing and complex logic added by simplified syntax.

Manufacturing facilities now depend entirely on automation processes for their rapid operations. Structured Text, the programming language, is playing a significant role in improving machine efficiency and intelligence. The programming language operates in the background to maintain smooth production line operation particularly when precise and expedient processing requirements are in effect.

Structured Text demonstrates its peak operating capacity for complex PLC systems that need to operate at an advanced level. Structured Text serves as the ideal solution for executing calculations together with loops and handling extensive data operations. You can find Structured Text implemented in most machines including packaging equipment and water treatment facilities that require dependable flexibility.

Introduction to PLC Programming Languages

Multiple programming languages are available for PLC programming. Ladder Logic stands as the most frequently used programming language that presents itself through electrical diagrams. Programmers utilize Function Block as a visual programming method which performs well for control requirements. The programming language Structured Text operates with written programming code which excels in mathematical and logical tasks. Two additional programming languages exist yet they receive less usage now—Instruction List and Sequential Function Chart. With personal strengths, these languages are most effectively utilized on the basis of the particular needs of the work.

Selecting an appropriate language produces a major impact on outcomes. Tasks that require swift logic operation benefit best from Ladder programming due to its advantages in this field. The selection of Structured Text becomes ideal for tasks that demand data processing or calculation purposes. The selection depends on project details together with team capabilities and system requirements. The correct programming selection leads to improved performance together with prevention of mistakes that result in smooth operation of machinery.

What Is Structured Text (ST)?

Structured text is the most common high level approach used for PLC programming. Structured Text behaves like conventional programming languages through its appearance and code structure which resembles Pascal and C code systems. The clear formatting and readability enable you to set your logic by writing text code lines. Structured Text provides a language structure that efficiently handles diverse operations such as loops along with conditions and data handling tasks. Structured Text provides excellent functionality because it delivers clear structure and detailed control.

The operation of Structured Text differs from how graphical programming PLC systems function. The combination of visuals provides assistance but text delivers additional depth together with flexibility.

Here is a simple comparison:

• Structured Text: Best for advanced logic and math-heavy processes

• Ladder Logic: Great for simple control tasks and troubleshooting

• Function Block: Ideal for repeated functions and visual clarity

• ST saves space and offers cleaner code in complex systems

• But graphical languages may feel easier for beginners or electricians

Syntax and Structure of Structured Text

The code blocks in Structured Text present clear straightforward text for PLC programming purposes. Your program defines variables that save information including numeric figures and timing values. The programming language allows repeated action execution through loops that continue running until specified conditions become true. Your application benefits from IF statements when making program decisions. The structure makes controlling elaborate operations simpler to handle. All components execute strictly according to the sequence just as you would follow instructions listed step by step.

The line between ST programming and Pascal and C programming notation seems minimal to me. The language semicolon structure together with its logic shows similarities with modern programming codes. No new system needs to be learned since you can write code using established rules. Switching programming tasks from conventional coding to PLCs becomes easier for professionals because of this feature. The technique will benefit beginners more than established users. Below are

5 basic Structured Text (ST) examples for beginners in the PLC programming field:

1. Start/Stop Motor (Latching Circuit)

IF StartButton = TRUE AND MotorRunning = FALSE THEN

MotorRunning := TRUE;

END_IF;

IF StopButton = TRUE THEN

MotorRunning := FALSE;

END_IF;

Motor := MotorRunning;

Explanation:

• Pressing StartButton sets MotorRunning to TRUE.
• Pressing StopButton resets it.
• Motor output is tied to the running status.

2. Light Control (Momentary Pushbutton)

IF LightButton = TRUE THEN

Light := TRUE;

ELSE

Light := FALSE;

END_IF;

Explanation:

• Light stays ON only while the button is pressed.

3. Fan Delay Start Using TON Timer

TON1(IN := StartButton, PT := T#5s);

IF TON1.Q = TRUE THEN

Fan := TRUE;

ELSE

Fan := FALSE;

END_IF;

Explanation:

• When StartButton is pressed, the timer waits 5 seconds (T#5s) before turning on the fan.

4. Blinking Light Using Timer

TON1(IN := NOT TON1.Q, PT := T#1s);

Light := TON1.Q;

Explanation:

• This creates a blinking effect by toggling the timer every 1 second.
• The light blinks ON and OFF with a 1-second interval.

5. Box Counter With Light at 10 Count

IF Sensor = TRUE AND LastSensor = FALSE THEN

Count := Count + 1;

END_IF;

LastSensor := Sensor;

IF Count >= 10 THEN

BoxLight := TRUE;

ELSE

BoxLight := FALSE;

END_IF;

Explanation:

• Every rising edge of Sensor adds 1 to Count.
• When Count reaches 10, BoxLight turns ON.

Use Cases and Applications of Structured Text

Structured Text provides an optimal solution for carrying out tasks which demand complex logic sequences. The PLC programming language easily operates complex algorithms as well as complicated numerical computations and sophisticated data handling. Structured Text functions as the optimal solution when dealing with substantial quantities of data and creating evolved sequences. Structured Text demonstrates high effectiveness when implementing PID control systems or when performing machine diagnostics tasks. The need for accurate data processing combined with easy comprehension makes ST an optimal selection.

Multiple industrial operations choose Structured Text as their standard method for automation. Industry applications of Structured Text include manufacturing plants as well as water treatment PLC systems and energy generation facilities and food processing facilities. Automotive plants together with building automation systems utilize this programming language. I believe ST suits any system requiring dependable flexible and complex control. The PLC system proves reliable in situations that cannot tolerate any mistakes.

Benefits and Limitations of Structured Text

Structured Text provides major advantages to users along with its implementation. Structured Text provides code which is clean while making it simple to reuse and suitable for complex projects. The solution grows conveniently without breaking your control or plunging into disorganized logic structures. The easier understandability of Structured Text enables better editing opportunities especially when working alongside other team members. Modular PLC PLC programming is supported through Structured Text making it possible to reduce complex programming tasks into smaller easily manageable sections.

Despite several benefits, Structured Text holds specific disadvantages which make it unfit for all programming needs. The learning steepness of this PLC technology becomes most challenging for individuals entering this field of coding. Due to its nature the logic structure remains invisible because everything exists as plain text. Problems in troubleshooting as well as complications for electricians arise due to this approach.

Here is a simple comparison:

Advantages	Limitations
Reusable and clean code	Harder to learn for beginners
Scales well for big tasks	Less visual, not ideal for quick checks
Easy to maintain	Requires coding knowledge

Getting Started with Structured Text

The initial requirement to work with Structured Text becomes obvious when you need proper tools. The widely accepted platforms include TwinCAT and Codesys and Siemens TIA Portal. The environments provide writers with tools to create and run ST programs through testing and execution features. Codesys functions as an excellent entry-level platform since automatic environment and ease of use features are provided free of charge. The majority of these tools enable simulation capabilities that enable training through virtual environments.

With the help of official documentation, along with interesting online courses and video tutorials, effective learning material can be obtained. Novice students should start with studying basic examples combined with smaller projects. The process of learning ST is simplified for developers when such clean code practices are coupled with commenting practices in regular testing reviews. Shipping experience through daily practice will make you both competent and self-assured.

FAQ’s

Conclusion

Structured Text serves advanced control functions and complex tasks while offering neat programming logic. The need for PLC system precision and flexibility makes Structured Text an appropriate programming solution. Learning Structured Text demands time yet provides exceptional benefits to programmers.

Future updates become simpler through ST because it provides PLC programmers with more control options. Through proper training along with regular practice any person can successfully learn Structured Text. Learning Structured Text programming creates new career opportunities within intelligent industrial sectors because of expanding automation technologies.
